• ADP171AUJZ-R7 Integrated Circuit Chip Ic Reg Lin Pos Adj 300ma Tsot23
ADP171AUJZ-R7 Integrated Circuit Chip Ic Reg Lin Pos Adj 300ma Tsot23

ADP171AUJZ-R7 Integrated Circuit Chip Ic Reg Lin Pos Adj 300ma Tsot23

Product Details:

Place of Origin: original
Brand Name: original
Certification: original
Model Number: ADP171AUJZ-R7

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiation
Packaging Details: carton box
Delivery Time: 1-3working days
Payment Terms: T/T
Supply Ability: 100,000
Get Best Price Contact Now

Detail Information

Product Status: Active Output Configuration: Positive
Output Type: Adjustable Number Of Regulators: 1
Voltage - Input (Max): 3.6V Voltage - Output (Min/Fixed): 0.8V
Voltage - Output (Max): 3V Voltage Dropout (Max): 0.135V @ 300mA

Product Description

ADP171AUJZ-R7 Integrated Circuit Chip Ic Reg Lin Pos Adj 300ma Tsot23



Linear Voltage Regulator IC Positive Adjustable 1 Output 300mA TSOT-23-5



Specifications of ADP171AUJZ-R7





TYPE DESCRIPTION
Category Integrated Circuits (ICs)
Power Management (PMIC)
Voltage Regulators - Linear
Mfr Analog Devices Inc.
Series -
Package Tape & Reel (TR)
Cut Tape (CT)
Product Status Active
Output Configuration Positive
Output Type Adjustable
Number of Regulators 1
Voltage - Input (Max) 3.6V
Voltage - Output (Min/Fixed) 0.8V
Voltage - Output (Max) 3V
Voltage Dropout (Max) 0.135V @ 300mA
Current - Output 300mA
Current - Quiescent (Iq) 60 µA
Current - Supply (Max) 260 µA
PSRR 73dB ~ 47dB (1kHz ~ 100kHz)
Control Features Enable
Protection Features Over Current, Over Temperature, Under Voltage Lockout (UVLO)
Operating Temperature
-40°C ~ 125°C
Mounting Type Surface Mount
Package / Case SOT-23-5 Thin, TSOT-23-5
Supplier Device Package TSOT-23-5
Base Product Number ADP171



Features of ADP171AUJZ-R7



Maximum output current: 300 mA

Input voltage range: 1.6 V to 3.6V

Low quiescent current

IGND = 23 µA with 0 mA load

IGND = 170 µA with 300 mA load

Low shutdown current: <1 µA

Low dropout voltage: 66 mV at 300 mA load

Output voltage accuracy: ±1%

Up to 31 fixed-output voltage options available from 0.8 V to 3.0 V

Adjustable-output voltage range 0.8 V to 3.0 V (ADP171)

Accuracy over line, load, and temperature: ±3%

Stable with small 1 µF ceramic output capacitor

PSRR performance of 70 dB at 10 kHz and 73 dB at 1 kHz

Low noise: 30 µV rms at VOUT = 0.8 V

Current limit and thermal overload protection

Logic-controlled enable

Compact 5-lead TSOT package



Applications of ADP171AUJZ-R7



Mobile phones Digital camera and audio devices

Portable and battery-powered equipment

DSP/FPGA/microprocessor supplies

Post dc-dc regulation



Environmental & Export Classifications of ADP171AUJZ-R7



ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001
