MCP23008T-E/ML I/O EXPANDER 8 I²C IC XPNDR 1.7MHZ I2C 20QFN 25MA
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | MCP23008T-E/ML |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Features: | POR | Product Status: | Active |
|---|---|---|---|
| Digi-Key Programmable: | Not Verified | Number Of I/O: | 8 |
| Interface: | I²C | Interrupt Output: | Yes |
| Output Type: | Push-Pull | Current - Output Source/Sink: | 25mA |
Product Description
MCP23008T-E/ML I/O EXPANDER 8 I²C IC XPNDR 1.7MHZ I2C 20QFN 25MA
|
I/O Expander 8 I²C 1.7 MHz 20-QFN (4x4)
|
Specifications of MCP23008T-E/ML
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Interface | |
| I/O Expanders | |
| Mfr | Microchip Technology |
| Series | - |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Product Status | Active |
| Digi-Key Programmable | Not Verified |
| Number of I/O | 8 |
| Interface | I²C |
| Interrupt Output | Yes |
| Features | POR |
| Output Type | Push-Pull |
| Current - Output Source/Sink | 25mA |
| Clock Frequency | 1.7 MHz |
| Voltage - Supply | 1.8V ~ 5.5V |
| Operating Temperature | -40°C ~ 125°C |
| Mounting Type | Surface Mount |
| Package / Case | 20-VFQFN Exposed Pad |
| Supplier Device Package | 20-QFN (4x4) |
| Base Product Number | MCP23008 |
Features of MCP23008T-E/ML
• 8-Bit Remote Bidirectional I/O Port - I/O pins default to input
• High-Speed I2C Interface (MCP23008)
- 100 kHz - 400 kHz
- 1.7 MHz
• High-Speed SPI Interface (MCP23S08)
- 10 MHz
• Hardware Address Pins
- Three for the MCP23008 to allow up to eight devices on the bus
- Two for the MCP23S08 to allow up to four devices using the same Chip Select
• Configurable Interrupt Output Pin
- Configurable as active-high, active-low or open-drain
• Configurable Interrupt Source
- Interrupt-on-change from configured defaults or pin change
• Polarity Inversion Register to Configure the Polarity of the Input Port Data
• External Reset Input
• Low Standby Current: 1 µA (max.)
• Operating Voltage:
- 1.8V to 5.5V at -40°C to +85°C I 2C at 100 kHz SPI at 5 MHz
- 2.7V to 5.5V at -40°C to +85°C I 2C at 400 kHz SPI at 10 MHz
- 4.5V to 5.5V at -40°C to +125°C I 2C at 1.7 kHz SPI at 10 MHz
Packages of MCP23008T-E/ML
Environmental & Export Classifications of MCP23008T-E/ML
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
