Part No: MCP1407T-E/MF Voltage - Supply: 4.5V ~ 18V
Logic Voltage - VIL, VIH: 0.8V, 2.4V Current - Peak Output (Source, Sink): 6A, 6A
Rise / Fall Time (Typ): 20ns, 20ns Operating Temperature: -40°C ~ 125°C

Product Description

 MCP1407T-E / MF Low-Side Gate Driver IC Non-Inverting 8-DFN-S (6x5)



Buck Switching Regulator IC Positive Adjustable 1.25V 1 Output 1.2A 8-SOIC (0.154", 3.90mm Width)



The MCP1406/07 devices are a family of buffers/MOSFET drivers that feature a single-output
with 6A peak drive current capability, low shoot-through current, matched rise/fall times and propagation delay
times. These devices are pin-compatible and are improved versions of the TC4420/TC4429 MOSFET drivers.



Features of MCP1407T-E/MF



• High Peak Output Current: 6.0A (typical)
• Low Shoot-Through/Cross-Conduction Current in
Output Stage
• Wide Input Supply Voltage Operating Range:
- 4.5V to 18V
• High Capacitive Load Drive Capability:
- 2500 pF in 20 ns
- 6800 pF in 40 ns
• Short Delay Times: 40 ns (typical)
• Matched Rise/Fall Times
• Low Supply Current:
- With Logic ‘1’ Input – 130 µA (typical)
- With Logic ‘0’ Input – 35 µA (typical)
• Latch-Up Protected: Will Withstand 1.5A Reverse
Current
• Logic Input Will Withstand Negative Swing up to 5V
• Pin compatible with the TC4420/TC4429 devices
• Space-saving 8-Pin SOIC, PDIP and
8-Pin 6 x 5 mm DFN Packages



Specifications of MCP1407T-E/MF



Mfr
Microchip Technology
Series
-
Product
MCP1407T-E/MF
Driven Configuration
Low-Side
Channel Type
Single
Number of Drivers
1
Gate Type
IGBT, N-Channel, P-Channel MOSFET
Voltage - Supply
4.5V ~ 18V
Logic Voltage - VIL, VIH
0.8V, 2.4V
Current - Peak Output (Source, Sink)
6A, 6A
Input Type
Non-Inverting
Rise / Fall Time (Typ)
20ns, 20ns
Operating Temperature
-40°C ~ 125°C
Mounting Type
Surface Mount
Package / Case
8-VDFN Exposed Pad
Supplier Device Package
8-DFN-S (6x5)
Base Product Number
MCP1407



range (−10 ̊

Environmental & Export Classifications


wh avck-

ATTRIBUTE DESCRIPTION
RoHS Status ROHS3 Compliant
Moisture Sensitivity Level (MSL) 1 (Unlimited)
REACH Status REACH Unaffected
ECCN EAR99
HTSUS 8542.39.0001



Application of MCP1407T-E/MF



• Switch Mode Power Supplies
• Pulse Transformer Drive
• Line Drivers
• Motor and Solenoid Drive
