TLV5604CDR Integrated Circuit Chip 10 Bit Digital To Analog Converter 4 16-SOIC
Product Details:
Place of Origin: | Original |
Brand Name: | Original |
Certification: | Original |
Model Number: | TLV5604CDR |
Payment & Shipping Terms:
Minimum Order Quantity: | 1 |
---|---|
Price: | negotiation |
Packaging Details: | carton box |
Delivery Time: | 1-3working days |
Payment Terms: | T/T |
Supply Ability: | 100,000 |
Detail Information |
|||
Number Of Circuits: | 4 | Voltage - Supply, Analog: | 2.7V ~ 3.3V, 5V |
---|---|---|---|
Voltage - Supply, Digital: | 2.7V ~ 3.3V, 5V | Architecture: | String DAC |
Operating Temperature: | 0°C ~ 70°C | Package / Case: | 16-SOIC (0.154", 3.90mm Width) |
Product Description
TLV5604CDR Integrated Circuit Chip 10 Bit Digital To Analog Converter 4 16-SOIC
Features of TLV5604CDR
Four 10-Bit D/A Converters
Programmable Settling Time
of 3 µs or 9 µs Typ
TMS320, (Q)SPI, and Microwire
Compatible Serial Interface
Internal Power-On Reset
Low Power Consumption:
5.5 mW, Slow Mode – 5-V Supply
3.3 mW, Slow Mode – 3-V Supply
Reference Input Buffers
Voltage Output Range ...2× the Reference
Input Voltage
Monotonic Over Temperature
Dual 2.7-V to 5.5-V Supply (Separate Digital
and Analog
Hardware Power Down (10 nA)
Software Power Down (10 nA)
Simultan
Product Attributes of TLV5604CDR
Product Status
|
Active
|
Digi-Key Programmable
|
Not Verified
|
Number of Bits
|
10
|
Number of D/A Converters
|
4
|
Settling Time
|
18µs
|
Output Type
|
Voltage - Buffered
|
Differential Output
|
No
|
Data Interface
|
SPI
|
Reference Type
|
External
|
Voltage - Supply, Analog
|
2.7V ~ 3.3V, 5V
|
Voltage - Supply, Digital
|
2.7V ~ 3.3V, 5V
|
INL/DNL (LSB)
|
±1 (Max), ±0.1
|
Architecture
|
String DAC
|
Operating Temperature
|
0°C ~ 70°C
|
Package / Case
|
16-SOIC (0.154", 3.90mm Width)
|
Supplier Device Package
|
16-SOIC
|
Mounting Type
|
Surface Mount
|
Base Product Number
|
Environmental & Export Classifications of TLV5604CDR
ATTRIBUTE | DESCRIPTION |
---|---|
RoHS Status | ROHS3 Compliant |
Moisture Sensitivity Level (MSL) | 2 (1 Year) |
REACH Status | REACH Unaffected |
ECCN | EAR99 |
HTSUS | 8542.33.0001 |
Applications of TLV4316QPWRQ1
plications
Battery Powered Test Instruments
Digital Offset and Gain Adjustment
Industrial Process Controls
Machine and Motion Control Devices
Communications
Arbitrary W
