L9680-TR Transistor Ic Chip Ic Interface Specialized 100tqfp
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | L9680-TR |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Product Status: | Active | Applications: | Automotive |
|---|---|---|---|
| Interface: | SPI | Voltage - Supply: | 5.5V |
| Package / Case: | 100-TQFP Exposed Pad | Supplier Device Package: | 100-TQFP (14x14) |
| Mounting Type: | Surface Mount | Base Product Number: | L9680 |
Product Description
L9680-TR Transistor Ic Chip Ic Interface Specialized 100tqfp
Automotive Interface 100-TQFP (14x14)
Specifications of L9680-TR
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Interface | |
| Specialized | |
| Mfr | STMicroelectronics |
| Series | Automotive, AEC-Q100 |
| Package | Tape & Reel (TR) |
| Cut Tape (CT) | |
| Digi-Reel® | |
| Product Status | Active |
| Applications | Automotive |
| Interface | SPI |
| Voltage - Supply | 5.5V |
| Package / Case | 100-TQFP Exposed Pad |
| Supplier Device Package | 100-TQFP (14x14) |
| Mounting Type | Surface Mount |
| Base Product Number | L9680 |
Features of L9680-TR
• AEC-Q100 qualified
• Boost regulator for energy reserve
– 1.882 MHz operation, Iload = 70 mA max
– Output voltage user selectable, 23 V/ 33 V ±5%
– Capacitor value & ESR diagnostics
• Boost regulator for PSI-5 SYNC pulse
– 1.882 MHz operation,
– Output voltage, 12 V/14.75 V, user configurable
• Buck regulator for remote sensor
– 1.882 MHz operation
– Output voltage, 7.2 V/9 V ±4%, user configurable
• Buck regulator for micro controller unit
– 1.882 MHz operation
– Output voltage user selectable, 3.3 V or 5.0 V ±3%
• Integrated energy reserve crossover switch
– 3 Ω - 912 mA max
– Switch active output indicator
• Battery voltage monitor & shutdown control with Wake-up control
• System voltage diagnostics with integrated ADC
• Squib/pyroswitch deployment drivers
– 12 channel HSD/LSD
– 25 V max deployment voltage
– Various deployment profiles
– Current monitoring
– Rmeasure, STB, STG & Leakage diagnostics
– High & low side driver FET tests
• High side safing switch regulator and enable control
• Four channel remote sensor interface
– PSI-5 satellite sensors
– Active wheel speed sensors
• Three channel GPO, HSD or LSD configurable, with PWM 0-100% control
• Nine channel hall-effect, resistive or switch sensor interface
• User customizable safing logic
• Specific disarm signal for passenger airbag
• Temporal and algorithmic Watchdog timers
• End of life disposal interface
• Temperature sensor
• 32 bit SPI communications
• 5.5 V minimum operating voltage at device battery pin
• Operating temperature, -40 to 95 °C
• Packaging - 100 pin
Ordering Information of L9680-TR
• Mid/High end airbag systems
• Cut-off battery systems
• Pyro Fuse/Pyroswitch management
Environmental & Export Classifications of L9680-TR
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | EAR99 |
| HTSUS | 8542.39.0001 |
