S5LS20216ASZWTQQ1 Microcontroller IC 16/32B 2MB FLASH 337NFBGA
Product Details:
| Place of Origin: | original |
| Brand Name: | original |
| Certification: | original |
| Model Number: | S5LS20216ASZWTQQ1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | negotiation |
| Packaging Details: | carton box |
| Delivery Time: | 1-3working days |
| Payment Terms: | T/T, L/C |
| Supply Ability: | 100,000 |
|
Detail Information |
|||
| Mfr: | Texas Instruments | Series: | Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R |
|---|---|---|---|
| Package: | Tray | Product Status: | Not For New Designs |
| Digi-Key Programmable: | Not Verified | Core Processor: | ARM® Cortex®-R4F |
| Core Size: | 16/32-Bit | Speed: | 160MHz |
| High Light: | S5LS20216ASZWTQQ1,337NFBGA Microcontroller IC,2MB Microcontroller IC |
||
Product Description
S5LS20216ASZWTQQ1 Current Sense Resistors Ic Mcu 16/32b 2mb Flash 337nfbga
ARM® Cortex®-R4F Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R Microcontroller IC 16/32-Bit 160MHz 2MB (2M x 8) FLASH 337-NFBGA (16x16)
Specifications of S5LS20216ASZWTQQ1
| TYPE | DESCRIPTION |
| Category | Integrated Circuits (ICs) |
| Embedded | |
| Microcontrollers | |
| Mfr | Texas Instruments |
| Series | Automotive, AEC-Q100, Hercules™ TMS570 ARM® Cortex®-R |
| Package | Tray |
| Product Status | Not For New Designs |
| Digi-Key Programmable | Not Verified |
| Core Processor | ARM® Cortex®-R4F |
| Core Size | 16/32-Bit |
| Speed | 160MHz |
| Connectivity | CANbus, EBI/EMI, LINbus, SCI, SPI, UART/USART |
| Peripherals | DMA, POR |
| Number of I/O | 115 |
| Program Memory Size | 2MB (2M x 8) |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| RAM Size | 160K x 8 |
| Voltage - Supply (Vcc/Vdd) | 1.35V ~ 1.65V |
| Data Converters | A/D 24x12b |
| Oscillator Type | External |
| Operating Temperature | -40°C ~ 125°C (TA) |
| Mounting Type | Surface Mount |
| Package / Case | 337-LFBGA |
| Supplier Device Package | 337-NFBGA (16x16) |
| Base Product Number | S5LS20216 |
FEATURES of S5LS20216ASZWTQQ1
• High-Performance Automotive Grade
Microcontroller for Safety Critical Applications
– Dual CPUs running in Lockstep
– ECC on Flash and SRAM
– CPU and Memory BIST (Built-In Self Test)
– Error Signaling Module (ESM) w/ Error Pin
• ARM® Cortex™-R4F 32-Bit RISC CPU
– Efficient 1.6 DMIPS/MHz with 8-stage pipeline
– Floating Point Unit with Single/Double Precision
– Memory Protection Unit (MPU)
– Open Architecture With Third-Party Support
• Operating Features
– Up to 160-MHz System Clock
– Core Supply Voltage (VCC): 1.5 V
– I/O Supply Voltage (VCCIO): 3.3 V
• Integrated Memory
– 1M-Byte or 2M-Byte Flash with ECC
– 128K-Byte or 160K-Byte RAM with ECC
• Multiple Communication interfaces including
FlexRay, CAN, and LIN
• NHET Timer and 2x 12-bit ADCs
• External Memory Interface (EMIF)
– 16bit Data, 22bit Address, 4 Chip Selects
• Common TMS470/570 Platform Architecture
– Consistent Memory Map across the family
– Real-Time Interrupt (RTI) OS Timer
– Vectored Interrupt Module (VIM)
– Cyclic Redundancy Checker (CRC, 2 Channels)
• Direct Memory Access (DMA) Controller
– 32 DMA requests and 16 Channels/ Control
Packets
– Parity on Control Packet Memory
– Dedicated Memory Protection Unit (MPU)
• Frequency-Modulated Zero-Pin Phase-Locked
Loop (FMzPLL)-Based Clock Module
– Oscillator and PLL clock monitor
• Up to 115 Peripheral IO pins
– 16 Dedicated GIO - 8 w/ External Interrupts
– Programmable External Clock (ECLK)
Applications of S5LS20216ASZWTQQ1
Packages Supported
– 144-Pin Quad Flat Pack (PGE) [Green]
– 337-Pin Ball Grid Array (ZWT) [Green]
• Community Resources
– TI E2E™ Online Community
Environmental & Export Classifications of S5LS20216ASZWTQQ1
| ATTRIBUTE | DESCRIPTION |
| RoHS Status | ROHS3 Compliant |
| Moisture Sensitivity Level (MSL) | 3 (168 Hours) |
| REACH Status | REACH Unaffected |
| ECCN | 3A991A2 |
| HTSUS | 8542.31.0001 |
